Features

• Robust mechanical components ensure exceptional durability.
• Two-year preventive maintenance schedule helps save money versus typical annual inspection requirements.
• Battery lasts approximately 3 years before a replacement is required.
• Sets not made with DEHP to protect patients. Needle-free sets protect both the patient and the clinician.
• Helpful prompts walk the user through the programming process.
• Easy to use, teach, and learn making it ideal for homecare settings.

Specifications

• Mechanism: Linear peristaltic volumetric infusion pump.
• Dimensions: 5.5 in (14 cm) x 9.4 in (24 cm) x 7.8 in (20 cm).
• Weight: 6.8 lb (3.1 kg).
• Power Requirements: 100 – 120 VAC, 50 – 60 Hz, 12 Watts.
• Leakage Current: Max 30 µA.
• Battery: 7.2 V, 1.2 Ah NiCd (rechargeable).
• Battery Operating Time: ~ 3.5 hours at 12 mL/hr.
• Rate Range: 0.1 to 800.0 mL/hr in 0.1 mL increments with Vista tubing.
• Volume to be Infused Range: 0.1 to 9999.9 mL.
• Occlusion Pressure: Variable Settings –

• Low: 8 PSI.
• High: 17 PSI.
• KVO Rate: 1 mL/hr or selected rate, whichever is lower.
• Flow Rate Accuracy: +/- 5% measurement time 8 hr, temp. 71.6° F.
• Alarms: Air-in-Line, low battery, plug-in-now, bag empty, downstream occlusion, door open, pump stopped, KVO, unit malfunction.
• Air-in-Line Alarm: Air bubble size 0.3 mL* or 1.5 mL/hr.**
• Memory: User option to retain last continuous and piggyback mode data upon power up. Permanent data retention in program and ramp/taper modes after pump is turned off.
• Tubing: B. Braun Vista administration sets.
• Modes/Features: Continuous and piggyback modes, program mode for variable infusions, ramp/taper mode fo TPN infusions and delay a mode for postponing infusion start and finish.
• Operating Temperatures:

• Operating: 64.4° to 95° F, 10.15 PSI to 15.37 PSI.
• Non-Operating: -14° F to 131° F, 10.15 PSI to 15.37 PSI.
• Latex Information: Components DO NOT contain natural rubber.
• Total Shelf Life: 35 months.
• Ordering Unit: ST.
• Sterile: No.
