Features

• Color LCD Twin Fetus Monitor
• Twin Fetus Heart Rates and Uterine Activity
• More Compact Probes and Robust Connectors
• Automatic Fetal Movement Detection
• Automatic TOCO Zeroing
• Clinical Mark and Note Entering
• CTG Interpretation
• 7” Wide Color LCD Viewer (800×480 Resolution)
• Touch Screen Operation Along with 10 Smart Keys for 16 Functions
• Graphic and Text Display Mode
• Yellow/Green LED Alarm Lamp for Easier Recognition
• 72-Hour Trace Data Reviewer
• USB Flash Drive Storage for Exporting JPG File to EMR
• High-Speed Printout of Stored Data
• Paper Feeding for Short Handwriting Memo
• Twin capability and automatic fetal movement
• 12 hours of memory capacity
• High-accuracy and wide detection area
• Easy on-screen access with scrolling function
• Durable watertight probes
• Easy-to-read A4 size chart paper
• High-speed printout of stored data
• Uses inexpensive fax paper
• s/w upgrade via the internet through RS-232C

Brochure

Bionet Twin View FC 1400 Fetal Monitor Brochure

Specifications

• Dimensions: 296 (w) x 305.5 (h) x 97.5 (d)mm
• Weight: Approximately 3.2kg (without battery)
• Display: 320 x 240 STN color LCD, 4.7 inch
• Recorder: Recorder Method: Thermal Array Type
• Resolution: 8 (vertical)/10 (horizontal) dot/mm
• Print Speed: 1, 2, 3, 12.5 cm/min
• External Link: RS232C: Program Download, Central (option)
• Temperature Range: Operating: 10 to 40° C
• Storage: -10 to 60° C
• Fetal Heart Rate: Input signal: Ultrasound Pulsed Doppler
• Ultrasound Frequency: 1.0 MHz
• Ultrasound Power: 10mW/cm2
• FHR Detection Method: Auto Correlation
• Measurement Range: 50-240 beats per minute (BPM)
• FHR Accuracy: +/- 1bpm over normal FHR range
• Uterine Activity: Input Source: External transducer with strain gauge
• Frequency Response: DC – 0.5 Hz
• Reference(Zero) Control: One touch switch
• Measurement Range: 0-99 units
