SKU: VC120

ConMed VisiClear Surgical Smoke Evacuator, 100/120V

$5,275.00

mydiscount Get a Discount

Questions? Speak with a Product Specialist!

mychat Chat with Us!
Live Chat
myphone Call Us!
888.354.2968
myemail Email Us!
Get in Touch

The Conmed VisiClear® Surgical Smoke Evacuator is one of the most advanced acute care offerings for surgical smoke evacuation. Combining Safeport Technology™, an occlusion warning, filter life tracking, and one-touch programmable procedure modes for open tubing, electrosurgical pencil, and laparoscopic procedures, VisiClear® effectively captures and filters surgical smoke, removes odors, particulates, and other potentially hazardous by-products. Whisper Technology™ ensures ultra-quiet operation with unprecedented sound quality.

For safety, VisiClear® utilizes SafePort Technology™, which ensures reduced risk of staff coming in contact with a contaminated port. An occlusion warning safety feature alerts medical personnel when an occlusion has occurred. The intuitive color touch screen is easy to use, requires minimal training, and can be operated with gloved hand.

Electrosurgery Brand

ConMed

Features

Procedure Operating Modes

  • One of three operating modes (Laparoscopic, Open Tubing, and Electrosurgical Pencil Mode) can easily be selected, automatically customizing filter life based on surgical procedure.

Advanced Sound Control Design

  • Whisper Technology™ ensures ultra-quiet operation with unprecedented sound quality.

Sleek Shelf Design

  • Ergonomically designed to accommodate stacking.

Occlusion Warning

  • Safety feature that alerts medical personnel when an occlusion has occurred.

Intuitive Color Touch Screen

  • Easy to use, requires minimal training, and can be operated with gloved hand.

Unique Sliding Port Closure

  • SafePort Technology™ ensures reduced risk of staff coming in contact with a contaminated port.

Specifications

Noise Levels (Nominal Values)

  • @ minimum power < 43 dBA
  • @ maximum power < 55 dBA

Dimensions (H x W x D)

  • 7.1 in x 13.9 in x 16.1 in
  • 18.0 cm x 35.4 cm x 40.9 cm

Flow Rates

  • 30 cfm (839 lpm) using 7/8 in (22 mm) tubing

Weight

  • With filter installed: 17.5 lbs (7.9 kg)
  • Without filter installed: 14.5 lbs (6.6 kg)

Static Suction

  • 150 mmHg vacuum

Certifications

  • UL, cUl, CE

Warranty

  • Three (3) Year Full Warranty
