Features

• Most advanced security level features in the medical cart market
• 3 lock types available: electronic (touchless RFID and touchscreen keypad), quick release, and keyed
• Powerful PC software included to manage your carts via secure Wi-Fi/Bluetooth
• Detailed audit employee tracking to mitigate narcotics theft
• One centralized point via the included PC software for all your employee access and updates
• Nearly unlimited configuration possibilities available
• Full-color touchscreen LCD with graphical menus on electronic carts
• Electronic cart alarms: audible alert (with timing settings) and e-mail/text notifications (up to 3 admins each)
• 3 different RFID frequencies available
• Up to 5,000 users available per electronic cart
• 10 standard colors and unlimited Pantone and RAL color options
• Unique quick release unlocking can save lives when a patient codes
• Quick release plunger with breakaway plastic tags and red/green flag can be reset easily by biomed
• Proprietary onboard and PC software developed by DETECTO
• User setup at the cart or within Windows software
• ABS thermoplastic countertop with molded edges that is all one continuous piece for optimal hygienic clean-up
• Dual authentication available in electronic carts: RFID and pin code touchscreen entry
• PC software allows you to update individual users, carts, locations/building, and departments
• Included PC software allows you to print, download, and export detailed history reports (holds up to 50,000 records)
• Tracking to check accountability of individual drawer inventory
• Multiple handrail configurations: all three sides, two, one, or none
• Seamless shell body without any exposed holes for flush clean lines and more aesthetically pleasing appearance
• Spacious soft-close drawers elegantly glide shut for convenience
• Aluminum cart body, high-impact plastic bumpers, and ABS countertop
• Two self-closing side extension trays included standard for additional counter space
• Standard full wrap-around high-impact bumper trim
• All four wheels are fully rotating caster-type wheels with two locking and two non-locking casters
• 5-in/13-cm diameter 1-wheel casters with features such as anti-static, total lock, and bead chain for static dissipation provide easy mobility for smooth transport and nimble maneuvering (2-wheel casters are optional)
• Versatile corner extrusion mounting for easy optional accessory attachment with customized locations
• Full range of accessories available: IV pole, sharps container holder, defibrillator shelf, cardiac board, oxygen tank holder, 12-bin organizer, catheter holder, waste bin, and many more
• Electronic cart unlocking with one lock and individual drawer sensors, individual drawer locks and individual drawer sensors, or simply one lock
• 12 Alkaline or rechargeable D batteries
• Made in USA (of American and foreign components): TAA compliant
• The most robust cart customization on the market to fit your needs

Specifications

Overall Dimensions (Height includes handrail; width and depth are to edge of bumpers)

• 16.5 in drawers: 43.9 in H x 27.0 in W x 26.7 in D (111.5 cm H x 68.6 cm W x 67.8 cm D)
• 23 in drawers: 43.9 in H x 33.5 in W x 26.7 in D (111.5 cm H x 85.1 cm W x 67.8 cm D)
• 29 in drawers: 43.9 in H x 39.5 in W x 26.7 in D (111.5 cm H x 100.3 cm W x 67.8 cm D)

Box Dimensions

• 16.5 in drawers: 27.0 in H x 16.5 in W x 18.0 in D (68.6 cm H x 41.9 cm W x 45.7 cm D)
• 23 in drawers: 27.0 in H x 23.0 in W x 18.0 in D (68.6 cm H x 58.4 cm W x 45.7 cm D)
• 29 in drawers: 27.0 in H x 29.0 in W x 18.0 in D (68.6 cm H x 73.7 cm W x 45.7 cm D)

Construction

• Cart Body: Aluminum – Cart top, bottom, sidewalls, drawer fronts and slides, corner extrusions, and 2 work trays
• Countertop: One-piece ABS thermoplastic with molded edges
• Bumpers: Wrap around high-impact ABS thermoplastic

Available Color Finish: 10 standard colors and all possible Pantone and RAL colors optional
Handrails: 0 to 3 (None, Back Only, Both Sides, Back and Both Sides)

Top Work Surface Dimensions

• 16.5 in drawers: 20.6 in W x in 19.0 D (52.3 cm W x 48.2 cm D)
• 23 in drawers: 27.1 in W x in 19.0 D (68.8 cm W x 48.2 cm D)
• 29 in drawers: 33.1 in W x in 19.0 D (84.1 cm W x 48.2 cm D)

Drawer Configuration (Drawer Height): 3 in, 6 in, 9 in, and 12 in (7.6 cm, 15.2 cm, 22.9 cm, and 30.5 cm)

Drawer Internal Dimensions

(Width x Depth)

• 16.5 in drawers: 16.4 in W x 17.9 in D (41.7 cm W x 45.5 cm D)
• 23 in drawers: 22.9 in W x 17.9 in D (58.2 cm W x 45.5 cm D)
• 29 in drawers: 28.9 in W x 17.9 in D (73.4 cm W x 45.5 cm D)

(Height)

• 3 in drawers: 2.6 in (6.6 cm)
• 6 in drawers: 5.6 in (14.2 cm)
• 9 in drawers: 8.6 in (21.8 cm)
• 12 in drawers: 11.6 in (29.5 cm)

Drawer Weight Capacity: 3 in, 6 in, and 9 in (7.6 cm, 15.2 cm, and 22.9 cm) = 50 lb (22 kg), 12 in (30.5 cm) = 100 lb (45 kg)
Wheel Diameter, Type: 5 in (12.7 cm), anti-static 1-wheel casters; two locking casters and two non-locking casters (2-wheel casters are optional)
Operating Environment: Operated Temperature Range: 14 to 104 ºF (-10 to +40 ºC), Humidity: 0 to 90% non-condensing
Storage Environment: Storage Temperature Range: -4 to 176 ºF (-20 to +80 ºC), Humidity: 0 to 95%
Country of Origin: USA

Lock Types Available:

• Keyed Lock
• Quick Release
• Electronic, Standard Lock
• Electronic, Standard Lock with Individual Drawer Sensors
• Electronic, Individual Drawer Lock with Individual Drawer Sensor

Display Type: 3.2 in (81.3 mm) diagonal, full-color TFT display, 320 x 240 resolution
Touch Screen: Resistive touch panel covering the display
Quick Release Button Diameter: 1.5 in (38.1 mm)
Communication Interfaces: Wi-Fi and Bluetooth
Alarm Duration: Continuous until Snooze is pressed or battery is depleted

RFID Types:

• 125kHz (“LF” HID compatible and EM4001 cards)
• 13.56 MHz (“HF” Proximity Cards, ISO/IEC 14443 A/B)
• 13.56 MHz (HF) Vicinity Cards and Tags, ISO/IEC 15693

PC Software Requirements: Windows 10 or greater or Windows Server 2016 or greater and SQL Express
PC Hardware Requirements: (SQL Express requirements)
Hard Disk: A minimum of 6 GB of available space
Memory: 1 GB Recommended
Processor: 2.0 GHz or faster recommended
Monitor: Super-VGA (800×600) or higher resolution monitor
Internet: For Internet functionality (fees may apply)
Cart Users Available: 5,000
PC Software Records Available: 50,000 records available in the audit trail
Power Requirements: 100 to 240V AC universal switching power supply or 12 “D” cell Alkaline, Ni-Cad or NiMH batteries (not included)
Battery Runtime*: 45 days with Alkaline batteries
30 days per charge on 10,000mAh NiMh batteries
*Battery runtime based on 20 unlock/lock cycles per day and 5 minutes of active time per hour.
Battery Recharge Time: 40 hours to recharge fully depleted 10,000mAh batteries

Net Weight

• 16.5 in Drawer Models: 148 lb (67.1 kg)
• 23 in Drawer Models: 163 lb (73.9 kg)
• 29 in Drawer Models: 188 lb (85.3 kg)

Shipping Weight

• 16.5 in Drawer Models: 203 lb (92.1 kg)
• 23 in Drawer Models: 218 lb (98.9 kg)
• 29 in Drawer Models: 243 lb (110.2 kg)
