Features

• Power Options
  Operates on AC line voltage or an internal battery that provides 12 hour runtime with a 4 hour quick recharge
• Easy to Read
  Bright LED displays and large screen allow easy reading, even from across the room
• Versatile and Capable
  Adaptable from acute care to homecare and neonates to adults; specified for use in motion and low perfusion
• Internal Memory
  Records up to 115 hours of data—ideal for extended monitoring
• User Friendly
  Three distinct icons offer helpful indications of signal status
• Flexible Alarms
  Includes patient security mode and user-defined default that offers customizable patient settings

Specifications

Oximeter

• Oxygen Saturation Range (%SpO2) …………………0% to 100%
• Pulse Rate Range…………………………………………..18 to 300 pulses per minute

Displays

• Numeric Displays………………………………………….3-digit LEDs, Tricolor (red, green, amber)
• Pulse Strength Indicator ………………………………..Tricolor LED
• Pulse Quality Indicator ………………………………….Amber LED
• LCD …………………………………………………………16 color; 256 x 64 pixels

Accuracy

Blood Oxygen Saturation (%SpO2 ±1 SD)b

• No Motion: Adults, Pediatrics …………….70–100% ±2 digits
• Neonates ……………………….70–100% ±3 digits
• Motion: Adults, Pediatrics …………….70–100% ±2 digits
• Neonates ……………………….70–100% ±3 digits
• Low Perfusion: Adults, Pediatrics …………….70–100% ±2 digits
• Neonates ……………………….70–100% ±3 digits

Pulse Rate

• No Motion………………………………………………18 to 300 bpm ±3 digits
• Motion …………………………………………………..60 to 240 bpm ±5 digits
• Low Perfusion………………………………………….60 to 240 bpm ±3 digits

Temperature

• Operating……………………………………………………+32° to +122°F (+0° to +50°C)
• Storage/Transportation ………………………………… -22° to +122°F (-30° to +50°C)

Humidity

• Operating……………………………………………………10% to 90% noncondensing
• Storage/Transportation …………………………………10% to 95% noncondensing

Altitude

• Operating……………………………………………………Up to 40,000 feet (12,192 m)

Power Requirements

• Mains …………………………………………………………100-240 VAC 50-60 Hz
• DC Input …………………………………………………….12 VDC 1.5A AC adapter

Internal Power

• Battery ……………………………………………………….7.2 volt battery pack (6 cells)
• Operating……………………………………………………Minimum 12 hours of continuous operation with a fully charged battery pack and LCD backlight off. Minimum 8 hours of continuous operation with a fully charged battery pack and LCD backlight on.
• Storage ………………………………………………………27 days
• Recharge…………………………………………………….4 hours

Dimensions …………………………………………………..7.25” wide x 5.5” high x 4.5” deep
18.4 cm x 14 cm x 11.4 cm
Weight (excluding Pole Mount System) ………………2.4 pounds (1.1 kg)
Memory ………………………………………………………..115 hours non-volatile

Warranty ………………………………………………………3 years

Classifications per IEC 60601-1/UL60601-1

• Type of Protection…………………………………………Class II (when on AC power with MPP30 battery charger)
• Internally powered (on battery power)
• Degree of Protection……………………………………..Type BF-Applied Part
• Enclosure Degree of Ingress Protection ……….. IPX2

Nurse Call

• Maximum Voltage …………………………………………30 V, AC or DC
• Maximum Load Current…………………………………100mA
• Output Impedance ………………………………………..30 ohm (max)
• Output …………………………………………………………Normally Open or Normally Closed; switch selectable
• Output Connector………………………………………….0.141” miniature phone jack
