Features

• Internal Memory
  Allows user to review up to 70 hours of memory
• Flexible Alarms
  Includes patient security mode and user-defined default that offers customizable patient settings
• Pulse Strength Bar Graph
  Assess the patient’s status at a glance with a color-coded bar graph and a saturation level-related audible tone at each pulse
• Pulse Quality Indicator
  Detects patient movement or signal quality changes that may require sensor site stabilization
• PureSAT® Technology
  Leverages intelligent pulse-by-pulse filtering to provide precise oximetry measurements
• Versatile
  Can be used as a stand-alone device or interface with other equipment

Specifications

Oxygen Saturation Display Range: 0 to 100% SpO₂

Pulse Rate Display Range: 18 to 321 pulses per minute (BPM)

Displays:

• Pulse Quality: LED, amber

• Sensor Alarm: LED, amber

• Pulse Strength Bargraph: LED, bargraph, tri-color segments

• Alarm Indicator: LED, bi-color

• Alarm Silenced: LED, amber

• Numeric Displays: 3-digit, 7-segment LEDs, green

• Low Battery: LED, amber

Accuracy – Sensors: Declared accuracy for compatible sensors can be foundin Nonin’s Sensor Accuracy document.

Alarm Volume:

• High: 75 dBA

• Low: 63 dBA

Informational Tone Volume:

• High: 67 dBA

• Low: 55 dBA

Measurement Wavelengths and Output Power:^a

• Red: 660 nm @ 0.8 mW maximum average power

• Infrared: 910 nm @ 1.2 mW maximum average power

Memory: 70 hours (assuming continuous operation)
Temperature:

• Operating: 0 °C to 40 °C (32 °F to 104 °F)

• Storage/Transportation: -40 °C to 70 °C (-40 °F to 158 °F)

• Time (from storage) for monitor to be ready for its intended use:
  6 minutes to warm from -40 °C to 0 °C
  23 minutes to cool from 70 °C to 40 °C

Humidity:

• Operating: 10 to 90% noncondensing

• Storage/Transportation: 10 to 95% noncondensing

Altitude (Operating): Up to 4,000 meters (13,123 feet)

Hyperbaric Pressure: Up to 4 atmospheres

Power Requirements (Mains): 100-240 VAC 50-60 Hz

Internal Power:

• Battery: 7.2 volt NiMH battery pack

• Operating Life (fully charged battery): 16 hours minimum

• Storage Life: 21 days minimum

• Recharge Rate: 4 hours maximum

Dimensions: Approximately 219 mm (8.6”) W x 92 mm (3.6”) H x 142 mm (5.6”) D

Weight: Approximately 900 grams (2 lbs) with battery

Warranty: 3 years

Classification per ANSI/AAMI ES60601-1 and CAN/CSA-C22.2 No. 60601-1:

• Type of Protection: Class II (on AC power with MPP30 power supply). Internally powered (on battery power)

• Degree of Protection: Type BF-Applied Part

• Mode of Operation: Continuous

• Enclosure Degree of Ingress Protection: IP33

Analog Outputs:

• SpO₂ Output Range: 0-1 VDC (0-100% SpO₂), 1.27 VDC (out of track)

• Pulse Rate Output Range: 0-1 VDC (0-300 BPM), 1.27 VDC (out of track)

• Event Maker: 0 V (no event), 1 V (event occurred)

• Accuracy: ±2% (SpO₂), ±5% (Pulse Rate)

• Load Current: 2 mA maximum
