Features

Unsurpassed patient comfort and acceptance by using the Auto-Feedback-Logic AFL

• Significantly better night sleep for the patient through individualized inflation
• Gentle and fast measurement of blood pressure
• Maximum comfort thanks to correct-sized cuffs with ease of app

Easy handling in everyday office routine

• “Bluetooth” wireless, rapid read in/read out between the monitor and the computer
• “Infrared” as the Classic Interface. One single Interface for 24h monitors and home devices
• Easy transfer of data via Infrared to the computer
• “Standard” – just use the standard cable, USB or serial

Analysis software and patient management

• Precise graphics, early morning rise analysis, comparison profiles for ambulatory and stationary data, threshold values for children – reports for physician interpretation and patient presentation
• Interface to EMR and HIS (GDT, XML)
• The analyzing software HMS CS enables you to build up an “Interventional Telemetric Clinic” for better therapy management

Specifications

• Measurement range: Systolic (SYS): 60-290 mmHg, Diastolic (DIA): 30-195 mmHg
• Accuracy: ± 3 mmHg
• Pressure range: 0 to 300 mmHg
• Pulse range: 30 to 240 bpm
• Measurement method: Oscillometric
• Measurement protocols: 4 freely editable day/night intervals, Measurements per hour: 1, 2, 5, 6, 10, 15, 20 or 30, Optional: automatic transfer of Blood Pressure values via GSM
• Memory: 300 measurements
• Battery capacity: up to 300 measurements
• Operating temperature range: +10 °C to +40 °C
• Operating air humidity range: 15% to 90%
• Storage conditions: 20 °C to +50 °C temp and 15% to 90% humidity
• Dimensions: 128x75x30mm
• Weight approx.: 240g including batteries
• Power supply: 2 IEM rechargeable Ni-MH batteries (12 V and min. 1700 mAh)
• Interfaces: Serial port (cable) compatible for USB Emulation, Infrared, Bluetooth (Class 1/100m)
